CHASSIS:

Frame steel double cradle frame

Wheel base 1410 mm

Max length 2115 mm

Max width 820 mm

Max height 1215 mm

Seat height 925 mm

Ground clearance 335 mm

Footrest height 400 mm

Dry weight 102 kg

Fuel tank capacity 7,3 l.

Reserve 1,5 l.

Front suspension USD Hydraulic fork ø41 mm

Rear suspension Monoshock with progressive compound lever

Shock absorber stroke 131 mm

Front wheel travel 260 mm

Rear wheel travel 270 mm

Front brake disc ø260 mm

Rear brake disc ø220 mm

Front rim 21 x 1,6 - 36 holes

Rear rim 18 x 1,85 - 36 holes

Front tyre 90/90-21

Rear tyre 120/90-18

ENGINE:

Type Single-cylinder, 4-stroke, liquid cooled

Bore 52,0 mm

Stroke 58,6 mm

Displacement 124,6 cc

Compression ratio 11,2:1

Ignition Electronic 250W-14v

Spark plug NGK CR8E

Lubrication Forced with pump

Feeding Unleaded gasoline

Carburettor Keihin CVK 30

Clutch Wet multi-disc clutch

Transmission 6 speed

Secondary trasmission Z. 14/63

Engine oil SAE 15W/50
